Flow Control Speedgate Turnstile , High Security Gate Turnstile Entrance

Flow Control Speedgate Turnstile , High Security Gate Turnstile Entrance

Speedgate Turnstile

High Security Gate Turnstile

Security Gate Turnstile Entrance

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Office Barrier Gate
Single Core:1600*231*980mm; Dual Core: 1600*312*980mm
Passage Width:
600 (standard) ~1200mm
Dry Contact; RS485; RS232
Power Supply:
AC110~AC220 +/- 10%
5 Pairs Of IR Sensors
Application Environment:
1.2mm Thickess Stainless Steel
Driving Motor:
Brushless Servo Motor
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
film + EPE + Carton + Wooden Case
Supply Ability
1~10 units, 3~7 working days; 10~30 units, 10~15 working days; 30~50+ 15~20 working days.
Product Description

Pedestrian Access Control Turnstile Security Gate Flow Control Fastlane Turnstile




Please see product video in youtube link:


Product Description

HPT Sirius series turnstile gate is one of the latest appearance design from HPT Technology. AG-TX68162302 high-end speed gate from HPT Siruis series is a kind of entry control system made for high-security locations, like airports, governmental structures, and upscale business offices. To provide secure and effective access control for authorized people, these gates make use of cutting-edge technologies and sophisticated sensors.

The speed turnsitles are typically elegant and stylish, blending in perfectly with contemporary architectural styles. They can be significantly customized to fit the unique needs of various establishments. Turnstile barriers, LED illumination, and biometric sensors are a few common forms of customisation. To prevent unwanted access, the gates also have a number of security features like infrared sensors and anti-tailgating devices.

The speed gates are extremely effective and can move a lot of people through in a short period of time. High-speed motors and sensors that enable smooth, quick motions while upholding the highest level of security are included in them. Smart cards, fingerprint scanners, and facial recognition technologies are just a few of the access control tools that can be combined with the gates.

The speedlane gates have the ability to gather information and offer real-time insights on the traffic flow within a facility, which is one of their main advantages. Facility managers can use this functionality to identify potential security breaches and streamline access and leave procedures, enhancing overall security and productivity.

The optical speed gates are crucial for any institution that needs cutting-edge security and effective access control procedures, in order to sum up. These gates offer a smart solution for high-end security needs with their adaptable designs and cutting-edge security features.

Flow Control Speedgate Turnstile , High Security Gate Turnstile Entrance 0



Product Size single wing:1600*231*980mm
dual wing: 1600*312*980mm
Material SUS 304 stainless steel + SPCC
Thinkness Top:1.2mm+body1.2mm
Passage Direction Single directional/Bi-directional
Standard Channel Width 600mm (≤900mm optional)
Sensor 5 pairs of active infrared intrusion detector
Throughput Rate 40~60p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless Servo Motor
Acoustic Alarm Buzzer Alarm
LED Triple Color LED





1, The gate can be integrated with different access control devices including RFID reader, ID reader, face recognition device and fingerprinte recognition etc.

2, It is equipped with light and acoustic alarm when someone wants to break in without authorization .

3, The system will automatically cancel the passing rights if visitor did not pass within setting time.

3, If visitor was caught by the turnstile wings, the turnstile wings will open to avoid people get hurt.

4, The turnstile is equipped with protection mechanism to protect its driving motor and wings when someone bump into the turnstile arms.

5, The turnstile motherboard has fire protection port.


Customization Avaible

To do changes on gate appearance and settings or passage width to adapt to different projects, or if you are looking for a OEM factory to realize your speed gate design, you are always welcome.




This gate is specially designed for high end places like museum, exhibition hall, hotel,  campus, office building, residential community and parks etc.


Flow Control Speedgate Turnstile , High Security Gate Turnstile Entrance 1Flow Control Speedgate Turnstile , High Security Gate Turnstile Entrance 2
