Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate

Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate

Pedestrian Flap Barrier Gate

550mm Flap Barrier Gate

Flap Barrier Security Turnstile Gate

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Office, Hotel, Library, Metro Station, Ect.
Passage Width:
SUS304 Stainless Steel
Product Name:
Flap Barrier Turnstile
Payment & Shipping Terms
Product Description

Flap Barrier Gate Pedestrian Flap Barrier Security Turnstile Gate


Product Description

Our AG-TX21122803 flap barrier gate is a cutting-edge access control solution designed for commercial and public environments. This advanced system combines innovative technology with robust construction to provide reliable and efficient security, while also offering a sleek and modern look that complements any setting.

Whether installed in an office building, a shopping mall, a train station, or any other high-traffic area, the AG-TX21122803 barrier gate delivers superior performance in controlling pedestrian flow and preventing unauthorized access. Featuring bi-directional operation, adjustable speed and sensitivity settings, and multiple authentication methods such as RFID, fingerprint, and face recognition, this gate can meet a wide range of security and convenience needs.

What's more, the AG-TX21122803 flap barrier gate is easy to install, operate, and maintain, thanks to its user-friendly management capabilities and modular design. It is built to withstand harsh weather conditions, intense usage, and attempted tampering, ensuring a long service life and a high return on investment.

Overall, the AG-TX21122803 flap barrier gate offers an intelligent and elegant solution for access control, adding value and prestige to any public or private space.


Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 0


Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 1

Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 2Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 3Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 4Pedestrian Flap Barrier Gate , Flap Barrier Security Turnstile Gate 5



Product Size 1200*280*960mm
Material SUS 304 stainless steel
Thickness Top:1.2mm+body1.0mm
Passage Direction Single directional/Bi-directional
Passage Width 550MM
Sensor 3 pairs of active infrared intrusion detector
Throughput Rate 30p/m
Reaction Time 0.2S
Driving Voltage DC24V 4.2A
Working Temperature ·-20~+70
Motor Brushed DC Motor
Mechanism Half Height Flap Gate Mechanism
Back up power Supercapacitor(12V/3A)
Indication LED direction indication
LED Single color LED



1. The flap barrier gate checks for errors when it is opened and sounds a warning siren if any are found.

2. At the main control panel, the operating state of the flap gate can be predetermined.

3. There is a stop-pinching feature. When the turnstile arms are about to close, the gate will automatically open to safeguard the travelers as well as the gate itself.

4. The flap barrier turnstile gate has an audible and visible alarm. When the gate is in standby mode, its LED is blue. When someone treads on it, green light comes out of it. When someone tries to use the gate route without permission, it flashes red. To alert persons of the authorization violation, the bell on the gate beeps.

5. The gate also incorporates "Anti-Collision" technology, allowing the driving motor to halt and attempt self-defense in the event that something slams into it too violently.

6. The data from the turnstiles is synchronized using a variety of channels.

7. If the visitor does not pass within the allotted time, the system will automatically withdraw their access permission, and it will by default return to the "waiting for open" status after 6 seconds. The user can choose the amount of time they wish to wait before the gate reopens using the "waiting duration" parameter.

8. Whenever the electricity is turned on and off, the turnstile will automatically open and close.

9. It can be connected to a variety of readers, including those that make use of RFID, facial recognition, and fingerprint recognition.

10. In order to limit entry and leave, a walkway may be one way or two ways.


Customization Available

To make our gate more suitable for your projects, we can also do different settings for the gate or change the gate design for different scenarios. You are always welcome to communicate with our sales team.
