Retractable Optical Turnstile SUS304 For Gym / Metro Station

Retractable Optical Turnstile SUS304 For Gym / Metro Station

Retractable Optical Turnstile

Metro Station Optical Turnstile

SUS304 Gym Turnstiles

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Flap Barrier Gate
SUS304 Stainless Steel
Passage Width:
Office, Hotel, Library, Metro Station, Ect.
Payment & Shipping Terms
Product Description

AG-TX28161502 New Design 304 Stainless Steel Retractable Turnstile Optical Turnstile for Gym


Product Video, please find in this youtube link:


Product Description

One of the newest aesthetic designs from HPT Technologies is the turnstile gate of the Sirius series. High end flap barrier gate from this series is model AG-TX28161502. The HPT Sirius flap barrier gate features a long and narrow body, which gives it a more delicate and contemporary appearance when compared to standard flap barrier turnstiles. The flap barrier gate turnstile is embellished with colored LEDs, which not only makes the gate more eye-catching during the day and at night, but also provides an intuitive status indication. Its design is complicated due to the use of several color techniques on the turnstile gate surface. It is distinctive, cutting-edge, and lovely.

Retractable Optical Turnstile SUS304 For Gym / Metro Station 0



Product Size 1600*300*980mm
Material SUS 304 stainless steel
Thickness Top:1.2mm+body1.2mm
Passage Direction Single directional/Bi-directional
Standard Channel Width 550mm
Sensor 4 pairs of active infrared intrusion detector
Throughput Rate 30~35p/m
Reaction Time 0.2S
Driving Voltage DC24V 4.2A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless DC Motor
Mechanism Full Height Flap Gate Mechanism
Back up power Supercapacitor(12V/3A)
Acoustic Alarm Buzzer Alarm
LED Triple Color LED

Retractable Optical Turnstile SUS304 For Gym / Metro Station 1

Retractable Optical Turnstile SUS304 For Gym / Metro Station 2


1. When this flap barrier gate is turned on, it performs a fault self-check and sounds a warning siren if it finds any problems.

2. At the main control panel, the operating state of the flap gate can be preset.

3. It features an anti-pinch feature. To prevent harming both people and the gate itself, the gate will reopen if the turnstile arms come into contact with something as they are ready to close.

4. The flap barrier turnstile gate has an audible and visual alarm. When the gate is in the standby state, the LED is blue; when people pass through the gate, it is green; and when people try to enter the gate passage without permission, the LED turns red and the buzzer in the gate beeps to alert people to the authorization violation.

5. The gate is also "Anti-Collision": If something slams into it too forcefully, the driving engine will shut off and attempt to defend itself from the impact's damage.

6. Different channels' data for turnstiles is synchronized.

7. If the visitor does not pass within the allotted time, the system will automatically cancel the visitor's access permission, and it will return to the "waiting for open" status after 6 seconds by default. Users can also change the "waiting duration" to control when the gate will start working again.

8. When power-off and power-on, the turnstile will automatically open and close.

9. It may be connected to several readers, including facial recognition, RFID, and fingerprint readers.

10. Accessing for entry and exit can be controlled in either a single direction or a two-way route.


Customization Available

To make our gate more suitable for your projects, we can also do different settings for the gate or change the gate design for different scenarios. You are always welcome to communicate with our sales team.



Retractable Optical Turnstile SUS304 For Gym / Metro Station 3

Retractable Optical Turnstile SUS304 For Gym / Metro Station 4
