SUS304 Stainless Steel Flap Barrier Turnstile Factory Security Speed Gates

SUS304 Stainless Steel Flap Barrier Turnstile Factory Security Speed Gates

Stainless Steel Flap Barrier Turnstile

Flap Barrier Turnstile Factory

SUS304 Security Speed Gates

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
SUS304 Stainless Steel
Product Name:
Flap Barrier Gate
Power Supply:
Indoor / Outdoor
1 Year
Payment & Shipping Terms
Product Description

AG-HX27123002 SUS304 Stainless Steel Flap Barrier Turnstile Retractable Barrier Gate


Product Description

AG-HX27123002 flap barrier gates is an innovative access control device that has become increasingly popular in recent years. They are frequently employed to control access and boost security in public spaces including subway stations, airports, office buildings, and retail centers. A barrier arm on a flap barrier, a sort of turnstile, can move vertically to let or prohibit entrance to those who are allowed.


The flap barrier gates' main purpose is to regulate access and stop unauthorized entry. The gates have sensors that can identify people's presence, allowing for easy and secure entrance. To accommodate the flow of traffic, the barriers can be operated in a number of ways, including uni-directional and bi-directional. In order to improve security and offer real-time data analysis, they are also made to integrate with other security tools like face teminals, card readers, and biometric scanners.


The retractable Barrier gate can be created to meet a variety of requirements and preferences. These can be customized to complement the aesthetic of the installation location and are available in a range of materials, such as stainless steel or tempered glass. They are a solid and affordable access control solution due to their great durability and low maintenance requirements.


An innovative and efficient access control solution that improves security and control in public spaces is the use of the flap barrier gates. They provide long-term performance and cost savings since they are highly adaptable, robust, and dependable. Flap barrier gates are a great alternative if you're looking for a sophisticated access control solution.

SUS304 Stainless Steel Flap Barrier Turnstile Factory Security Speed Gates 0


Product Size 1200*300*980mm
Material SUS 304 stainless steel
Thickness Top:1.2mm+body1.0mm
Passage Direction Single directional/Bi-directional
Passage Width 550mm
Sensor 3 pairs of active infrared intrusion detector
Throughput Rate 30~35p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless DC Motor
Mechanism Half Hight Flap Gate Mechanism
Back up power Supercapacitor(12V/3A)
Indication LED direction indication
Acoustic Alarm Buzzer Alarm
LED Triple Color LED




1. This flap barrier gate conduct fault self-check when it is turned on and it has siren prompt if it detects faults during its turning on.

2. The operation status of the flap gate can be programmed at the main control panel.

3. It has anti-pinch function. If the turnstile arms catch something when they are about to close, the gate will open again to avoid hurting people and the gate itself.

4. The flap barrier turnstile gate has acoustic and light alarm: When the gate is on standby status, LED on the gate is blue, when visitors passing the gate, it is green, and when visitors are not authorized but tried to enter the gate passage, the LED will turn red and buzzer in the gate will beep to give prompt of authorization violation.

5. The gate is also “Anti-collision”: If something bumps into the gate too hard, its driving motor will stop working and tried to protect itself from damage of the impact.

6. The data of turnstiles in different channels is synchronized.

7.. The system will automatically cancel the visitor's access permission if the visitor did no pass within the setting time, and it will resume to "waiting for open" status after 6 seconds by default, and users can also adjust the “waiting duration” when the gate will resume to work..

8. The turnstile will automatically open after power-off and close automatically after power-on.

9. It can be linked with a variety of readers like fingerprint reader, RFID reader, QR reader, and face recognition etc.

10. Single direction or two-way direction control of accessing for entry and exit is available.

SUS304 Stainless Steel Flap Barrier Turnstile Factory Security Speed Gates 1


Customization Available

To make our gate more suitable for your projects, we can also do different settings for the gate or change the gate design for different scenarios. You are always welcome to communicate with our sales team.
