Speedlane Pedestrian Swing Barrier Turnstile Access Control System

Speedlane Pedestrian Swing Barrier Turnstile Access Control System

Speedlane Swing Barrier Turnstile

Pedestrian Swing Barrier Turnstile

Turnstile Access Control System

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Pedestrian Swing Gate
SUS 304 Stainless Steel
Brushless Servo Motor
Top: 1.2mm+body: 1.2mm
Standard Channel Width:
5 Pairs Of Active Infrared Intrusion Detector
Throughput Rate:
40~60 P/M
Reaction Time:
Working Temperature:
Payment & Shipping Terms
Minimum Order Quantity
Product Description

SUS304 Stainless Steel Speedlane Pedestrian Swing Gate For Pedestrian Access Control



Product Video, please find in this youtube link:


Product Description


Searching for a sophisticated pedestrian access control solution? Look no farther than our premium swing barrier gate!



HPT Sirius series turnstile gate is one of the latested appearance design from HPT Technology. The AG-TX38161502 pedestrian swing gate

is designed to enhance the safety and security of buildings by efficiently restricting unauthorized access while allowing quick and seamless entry and exit of authorized persons.


The turnstile barriers are made from high-quality stainless steel and feature smooth and effortless operation. The device is equipped with advanced technology such as motion sensors and intelligent control modules, ensuring unbeatable accuracy and reliability. Furthermore, it can be easily customized to include features such as RFID readers or facial recognition technology, adding a layer of security and control.


The minimalist and sleek design of the turnstile barriers fits seamlessly with the interior design of modern offices, ensuring a classy and elegant look. The device has been tested rigorously to ensure durability and robustness, making it suitable for high-traffic areas and busy environments.


Our pedestrian access control system with turnstiles is easy to install and maintain, with minimal downtime for repairs and upgrades. We also offer comprehensive customer support and training to ensure the smooth operation of your system.


Ensuring safety and security for your employees, visitors, and valuables is crucial. Trust our pedestrian access control system to provide you with the best solutions in the market.

Speedlane Pedestrian Swing Barrier Turnstile Access Control System 0




Product Size 1600*150*980mm
Material SUS 304 stainless steel
Thickness Top:1.2mm+body1.2mm
Passage Direction Single directional/Bi-directional
Standard Channel Width 600mm (≤900mm optional)
Sensor 5 pairs of active infrared intrusion detector
Throughput Rate 25~30p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless Servo Motor
Mechanism Brushless Anti-collision Integrated Mechanism
Back up power Supercapacitor(12V/3A)
Acoustic Alarm Buzzer Alarm
LED Triple Color LED




1. AG-TX38161502 swing barrier gate arms opening speed can be set to meet various scenes requirements.


2. The gate has fault auto-inspection when it is turned on , the gate arms go back to position automatically after it is shut down or power off. It also does auto-inspeciton when it open and sends alarms when finds defects.


3. It supports multiple working modes choices,like single-way, double-way reading cards, each time only one person pass or waiting for all persion to pass etc.


4. The siwng barrier gate has anti-collision function: when the gate arms bump into something during closing, it will open again, or if it is a very hard bump the motor will stop working within ruled time to protect itself from damaging. It will close again after default delaying.


5. This gate also has anti-pinch function: When passsenger passing the gate, the sensors on gate will keep it open to make sure visitor passing the gate passage safely. If it senses people rushing in when it is about to close, the gate baffle wing will also open again to try not to catch people.


6. The gate is waterproof, sunproof, cold-resistant and high temperature resistance which is applicable for both indoor and outdoor.


7. The turnstile gate can work with different access control system like RFID card system , IC card system, face recognition system and fingerprint recognition system etc.



Customization Avaible

To do different passage width for the gate to work for different projects, or to do your customization optical swing barrier gate design , and any kinds of customization is available.

Speedlane Pedestrian Swing Barrier Turnstile Access Control System 1

Speedlane Pedestrian Swing Barrier Turnstile Access Control System 2Projects

Speedlane Pedestrian Swing Barrier Turnstile Access Control System 3
