30P/M Swing Barrier Turnstile Gym 1400*185*1020mm Half Height Building Turnstiles

30P/M Swing Barrier Turnstile Gym 1400*185*1020mm Half Height Building Turnstiles

30P/M Swing Barrier Turnstile

Swing Barrier Turnstile Gym

Half Height Building Turnstiles

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Half Height Turnstile
SUS 304 Stainless Steel
Standard Channel Width:
4 Pairs Of Active Infrared Intrusion Detector
Product Name:
Optical Swing Barrier Gate
Dry Contact
Payment & Shipping Terms
Minimum Order Quantity
Product Description

Access Rate 30P/M Optical Turnstile Swing Turnstile Gate

Product Description

AG-HX36141802 swing barrier gate is a dependable security option that offers efficient entry control for high-security zones is a high-end pedestrian turnstile. It is the perfect answer for anyone wishing to improve the safety and security of their premises because to its secure and reliable features, adaptable design, and simple interaction with other security systems.

It is an essential device that ensures the safety and security of pedestrian traffic in both indoor and outdoor environments. It is designed to provide controlled access to restricted areas and prevent unauthorized entry of visitors. The waterproof feature of the turnstile makes it ideal for use in areas exposed to water, such as stadium, sports facilities, and spas etc.


30P/M Swing Barrier Turnstile Gym 1400*185*1020mm Half Height Building Turnstiles 0



Product Size 1400*185*1020mm
Material SUS 304 stainless steel
Thickness Top:1.5mm+body1.2mm
Passage Direction Single directional/Bi-directional
Passage Width 600mm (≤900mm optional)
Sensor 4 pairs of active infrared intrusion detector
Throughput Rate 25~30p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless DC Motor
Mechanism Brushless Anti-collision Integrated Mechanism
Back up power Supercapacitor(12V/3A)
Indication LED direction indication
Acoustic Alarm Buzzer Alarm
LED Triple Color LED


• Offers improved access control and security


• Prevents unapproved entrance and exit


• Lessens the requirement for security guards


• Improves productivity and decreases pedestrian wait times


• A design that can be modified to fit into the environment.




1. AG-HX36141802 swing barrier gate arms opening speed can be set to meet various scenes requirements.


2. The gate has fault auto-inspection when it is turned on , the gate arms go back to position automatically after it is shut down or power off. It also does auto-inspeciton when it open and sends alarms when finds defects.


3. It supports multiple working modes choices,like single-way, double-way reading cards, each time only one person pass or waiting for all persion to pass etc.


4. The siwng barrier gate has anti-collision function: when the gate arms bump into something during closing, it will open again, or if it is a very hard bump the motor will stop working within ruled time to protect itself from damaging. It will close again after default delaying.


5. This gate also has anti-pinch function: When passsenger passing the gate, the sensors on gate will keep it open to make sure visitor passing the gate passage safely. If it senses people rushing in when it is about to close, the gate baffle wing will also open again to try not to catch people.


6. The gate is waterproof, sunproof, cold-resistant and high temperature resistance which is applicable for both indoor and outdoor.


7. The turnstile gate can work with different access control system like RFID card system , IC card system, face recognition system and fingerprint recognition system etc.

Customization Avaible

To do different passage width for the gate to work for different projects, or to do your customization optical swing barrier gate design , and any kinds of customization is available.


30P/M Swing Barrier Turnstile Gym 1400*185*1020mm Half Height Building Turnstiles 1
