Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty

Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty

FCC Swing Barrier Turnstile

Swing Barrier Turnstile AC220V

Optical Metal Turnstile

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Optical Swing Barrier Gate
Optical Gate
SUS304 Stainless Steel
Net Weight:
Single Core 38kg/dual Core 44 Kg
Power Supply:
1 Year
Payment & Shipping Terms
Product Description

AG-PX36121802 Brushless DC Motor Turnstile Entry Systems Swing Barrier Gate


AG-PX36121802 swing barrier gate can be used in various access control systems to manage the entry and exit of individuals. The gate provides enhanced security, as it can prevent unauthorized persons from gaining access to a restricted area. The swing barrier gates is specifically designed to control the flow of people, allowing only one person at a time to pass through the gate. The swing barrier gate can come in different sizes, shapes and materials, and can be customized to suit specific requirements. It is commonly used in airports, train stations, stadiums, museums, and office buildings, among other places. The automated swing barrier gate is equipped with sensors that detect the presence of a person and can be integrated with access control systems to enforce security measures. With the growing need for enhanced security measures, the swing barrier gates offer a convenient and efficient way of managing access control systems in different environments.

Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty 0

Please find product video in youtube link:


Product Size 1200*185*980mm
Material SUS 304 stainless steel
Thickness 1.2/1.5mm+1.0mm
Passage Direction Single directional/Bi-directional
Passage Width 600mm
Sensor 4 pairs of active infrared intrusion detector
Throughput Rate 25~30p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless DC Motor
Mechanism Brushless Anti-collision Integrated Mechanism
Back up power Supercapacitor(12V/3A)
Indication LED direction indication
Acoustic Alarm Buzzer Alarm
LED Triple Color LED

Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty 1


1, When this swing barrier gate is turned on, it performs a fault self-check and sounds a warning siren if it finds any problems. When the electricity is turned off and on, the turnstile will automatically open and close.

2, Control signal or button or remote control of the peripherals is available to achieve control accessing in single direction/bi direction.

3, Pass Authorization Rule: After visitor passes through the swing turnstile gate, the turstile arm automatically returns to its original position. If no access is made within the specified time, the system will cancel the passing authority.

4, The gate is equipped with high brightness LED accessing indicator

5, This swing barrier gate turnstile has audible and visual alarm. When the gate is in the standby state, the LED is blue; when people pass through the gate, it is green; and when people try to enter the gate passage without permission, the LED turns red and the buzzer in the gate beeps to alert people to the authorization violation.

6, The turnstile gate has a "Anti-Collision" feature that prevents damage from collisions by stopping the driving motor if something strikes the gate too hard.

7, The swing barrier gate system can be connected with It can be connected to many readers, including facial recognition, RFID, and fingerprint scanners etc. Its motherbroad has a fire protection port that can receive signals from the fire protection equipment, and when a fire alarm or blackout is detected, the gate barrier will automatically open.



Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty 2

Optical Metal Swing Barrier Turnstile AC220V / 110V 1 Year Warranty 3

Customization Available


In order to make our gate more appropriate for your projects, we may also change the gate's settings or design to fit various circumstances. Contacting our sales team is always an option.
