Anti Collision Sliding Barrier Gate , ESD Turnstile Gate System For Building

Anti Collision Sliding Barrier Gate , ESD Turnstile Gate System For Building

Anti Collision Sliding Barrier Gate

Building Sliding Barrier Gate

ESD Turnstile Gate System

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
Single Lane Flap Barrier
Single Core 38kg/dual Core 48 Kg
Brushless DC Motor
Swing Barrier
Payment & Shipping Terms
Product Description

AG-HX35141802 Pedestrian Access Control Bidirectional Turnstile Access Turnstile


HPT AG-HX35141802  Pedestrian Access Control Bidirectional Turnstile is a modern and efficient solution for controlled pedestrian access. Made of high-quality color coated SPCC, this turnstile is exceptionally durable, able to withstand heavy usage in high-traffic areas.

Designed with bi-directional movement, it allows for easy access in both directions while rigorously controlling pedestrian entry and exit. Its arm system ensures that only one person can pass at a time, so unauthorized traffic is impossible.

This turnstile is also designed with a user-friendly interface, making it easy to operate for both the pedestrians and the security personnel. It comes with an audio prompt to guide pedestrians through the access points.

With its sleek design and robust construction, the pedestrian access control bidirectional turnstile is the perfect solution for any facility that requires strict access control. It is commonly used in commercial buildings, airports, train stations, and other high-security areas where pedestrian traffic is high.

Anti Collision Sliding Barrier Gate , ESD Turnstile Gate System For Building 0



Product Size 1400*180*1000mm
Material SPCC
Thickness 1.2mm
Passage Direction single directional/Bi-directional
Passage Width 600mm (≤800mm optional)
Sensor 4 pairs of active infrared intrusion detector
Throughput Rate 25~30p/m
Reaction Time 0.2S
Driving Voltage DC24V 6.25A
Working Temperature ·-20~+70
Power Input AC110~220V±10%
Motor Brushless DC Motor
Mechanism Brushless Anti-collision Integrated Mechanism
Back up power Supercapacitor(12V/3A)
Indication LED direction indication
Acoustic Alarm Buzzer Alarm
LED Triple Color LED




Anti Collision Sliding Barrier Gate , ESD Turnstile Gate System For Building 1


1. Upon activation, this swing barrier gate conducts a fault self-check and, if any issues are discovered, emits a warning siren. When the electricity is switched off and on, the turnstile will automatically open and close.

2, Control signals, buttons, or remote controls are available for peripherals to enable control access in either a single way or a dual manner.

3, Pass Authorization Rule: The turnstile arm automatically returns to its initial position once a visitor goes through the swing turnstile gate. The passing authority will be revoked by the system if no access is made within the allotted time.

4, The gate has a high-luminance LED accessibility indicator.

5, There is an audible and visible alert on this swing barrier gate turnstile. The gate's LED is blue when it is in the standby mode, green when someone passes through it, and red when someone tries to enter the gate passageway without authorization. The buzzer in the gate beeps to warn individuals of the authorization violation.

6, The turnstile gate features a "Anti-Collision" mechanism that disables the driving motor if something impacts the gate too forcefully, preventing damage from collisions.

7, The swing barrier gate system is compatible with It can be connected to a variety of readers, such as fingerprint, RFID, and facial recognition scanners. When a fire alarm or blackout is detected, the gate barrier will automatically open because the motherbroad of the device contains a fire protection port that can receive signals from the fire protection equipment.

Anti Collision Sliding Barrier Gate , ESD Turnstile Gate System For Building 2



Customization Available

We may also alter the gate's settings or design to suit various situations in order to make it more suitable for your projects. You can always reach out to our sales staff.
